For light-duty applications where frequent washdowns are necessary. Ideally suited for applications exposed to cleaning agents, steam, caustic solutions, or other corrosive agents which could cause rust or corrosion.
- Polished Stainless Steel
- Perfect for Washdown and Corrosive Environments
FEATURES
- Top Plate & Yoke: Heavily embossed, Type 304 formed stainless steel to extend caster life under rugged conditions
- Swivel Section: Double stainless steel ball bearing raceways to resist wear and improve maneuverability
- Finish: “Polished” stainless steel finish maintains appearance in severe conditions
- Kingpin: 1/2” hydraulically formed stainless steel rivet
- Axle: 3/8” diameter Type 304 stainless steel hollow axle with lock nut
- Component Parts: Bushing, axle and nut are all stainless steel
- Locking brake available
- NSF Listed for food service industry
| 3" Rigid | 3" Swivel | |
|---|---|---|
| Caster Type: | Rigid | Swivel |
| Finish: | Stainless Steel | Stainless Steel |
| Wheel Desc.: | Phenolic | Phenolic |
| Wheel Bearing: | Plain Bore | Plain Bore |
| Wheel Diameter: | 3" | 3" |
| Wheel Width: | 1-1/4" | 1-1/4" |
| Overall Height: | 4-1/4" | 4-1/4" |
| Load Rating: | 350 lbs | 350 lbs |
| Swivel Lead: | -- | 1-5/16" |
| Mount Type: | Plate | Plate |
| Mount Plate: | 3-5/8" X 2-1/2" | 3-5/8" X 2-1/2" |
| Bolt Hole: | Slotted 3-1/16 to 2-13/16 by 1-3/4". 5/16" attaching bolt | Slotted 3-1/16 to 2-13/16 by 1-3/4". 5/16" attaching bolt |
| Brake: | Sold Seperately | Sold Seperately |
| Weight: | 1.5 lbs | 1.5 lbs |
*Rigid caster not pictured
